imt::base::bsp::module::DriverAbs< TypeId > Class Template Reference

Base class for all drivers in the BSP. More...

#include <Imt.Base.BSP/Driver/DriverAbs.h>

Inheritance diagram for imt::base::bsp::module::DriverAbs< TypeId >:

Public Member Functions
	DriverAbs (const size_t indexModule, const size_t indexDriver)
	Constructor. More...
virtual	~DriverAbs (void)
	Destructor. More...
void	initialize (void)
	Initialize the driver. More...
void	enable (void)
	Enable the driver. More...
imt::base::bsp::type::ErrorCode::Id	start (void)
	Starts the driver. More...
imt::base::bsp::type::ErrorCode::Id	stop (void)
	Stops the driver. More...
size_t	getIndexDriver (void) const
	Gets the index of the driver inisde the module. More...
size_t	getIndexModule (void) const
	Gets the index of the module the driver is part of. More...
imt::base::bsp::type::DriverType::Id	getType (void) const
	Gets the type of the driver. More...
bool	isInitialized (void) const
	Gets if the driver has been initialzied. More...
bool	isEnabled (void) const
	Gets if the driver has been enabled. More...
bool	isStarted (void) const
	Gets if the driver has been started. More...

Static Public Attributes
static const imt::base::bsp::type::DriverType::Id	Type = TypeId
	Constant holding the driver type. More...

Protected Member Functions
virtual void	onInitialize ()=0
	Called when the driver is initialized. More...
virtual void	onEnable ()=0
	Called when the driver is enabled. More...
virtual imt::base::bsp::type::ErrorCode::Id	onStart ()=0
	Called whenever the driver is started. More...
virtual imt::base::bsp::type::ErrorCode::Id	onStop ()=0
	Called whenever the driver is stopped. More...

Detailed Description

template<imt::base::bsp::type::DriverType::Id TypeId>
class imt::base::bsp::module::DriverAbs< TypeId >

Base class for all drivers in the BSP.

Constructor & Destructor Documentation

DriverAbs()

template<imt::base::bsp::type::DriverType::Id TypeId>

imt::base::bsp::module::DriverAbs< TypeId >::DriverAbs ( const size_t  indexModule, const size_t  indexDriver  )

inlineexplicit

Constructor.

Parameters

indexModule	Index of the module (starting at 0).
indexDriver	Index of the driver (starting at 0).

~DriverAbs()

template<imt::base::bsp::type::DriverType::Id TypeId>

virtual imt::base::bsp::module::DriverAbs< TypeId >::~DriverAbs ( void  )

inlinevirtual

Destructor.

Member Function Documentation

enable()

template<imt::base::bsp::type::DriverType::Id TypeId>

void imt::base::bsp::module::DriverAbs< TypeId >::enable ( void  )

inline

Enable the driver.

This includes enabling of required interrupts and clocks. This method is called once before the runtime is started.

getIndexDriver()

template<imt::base::bsp::type::DriverType::Id TypeId>

size_t imt::base::bsp::module::DriverAbs< TypeId >::getIndexDriver ( void  ) const

inline

Gets the index of the driver inisde the module.

Returns

The index (starting at 0).

getIndexModule()

template<imt::base::bsp::type::DriverType::Id TypeId>

size_t imt::base::bsp::module::DriverAbs< TypeId >::getIndexModule ( void  ) const

inline

Gets the index of the module the driver is part of.

Returns

The index (starting at 0).

getType()

template<imt::base::bsp::type::DriverType::Id TypeId>

imt::base::bsp::type::DriverType::Id imt::base::bsp::module::DriverAbs< TypeId >::getType ( void  ) const

inline

Gets the type of the driver.

Returns

The drive type.

initialize()

template<imt::base::bsp::type::DriverType::Id TypeId>

void imt::base::bsp::module::DriverAbs< TypeId >::initialize ( void  )

inline

Initialize the driver.

This includes configuration of all registers for the driver. This method is called once when the BSP is intitalized.

isEnabled()

template<imt::base::bsp::type::DriverType::Id TypeId>

bool imt::base::bsp::module::DriverAbs< TypeId >::isEnabled ( void  ) const

inline

Gets if the driver has been enabled.

Returns

True if the driver has been enabled.

isInitialized()

template<imt::base::bsp::type::DriverType::Id TypeId>

bool imt::base::bsp::module::DriverAbs< TypeId >::isInitialized ( void  ) const

inline

Gets if the driver has been initialzied.

Returns

True if driver is initialized.

isStarted()

template<imt::base::bsp::type::DriverType::Id TypeId>

bool imt::base::bsp::module::DriverAbs< TypeId >::isStarted ( void  ) const

inline

Gets if the driver has been started.

Returns

True if the driver has been started.

onEnable()

template<imt::base::bsp::type::DriverType::Id TypeId>

virtual void imt::base::bsp::module::DriverAbs< TypeId >::onEnable ( )

protectedpure virtual

Called when the driver is enabled.

See also

enable()

Implemented in imt::base::bsp::driver::UsartDriver, imt::base::bsp::driver::SpiDriver, imt::base::bsp::driver::PwmDriver, imt::base::bsp::driver::I2CDriver, imt::base::bsp::driver::HighLevelDriver, imt::base::bsp::driver::GpioDriver, imt::base::bsp::driver::DacDriver, imt::base::bsp::driver::CanDriver, and imt::base::bsp::driver::AdcDriver.

onInitialize()

template<imt::base::bsp::type::DriverType::Id TypeId>

virtual void imt::base::bsp::module::DriverAbs< TypeId >::onInitialize ( )

protectedpure virtual

Called when the driver is initialized.

See also

initialize()

Implemented in imt::base::bsp::driver::UsartDriver, imt::base::bsp::driver::SpiDriver, imt::base::bsp::driver::PwmDriver, imt::base::bsp::driver::I2CDriver, imt::base::bsp::driver::HighLevelDriver, imt::base::bsp::driver::GpioDriver, imt::base::bsp::driver::DacDriver, imt::base::bsp::driver::CanDriver, and imt::base::bsp::driver::AdcDriver.

onStart()

template<imt::base::bsp::type::DriverType::Id TypeId>

virtual imt::base::bsp::type::ErrorCode::Id imt::base::bsp::module::DriverAbs< TypeId >::onStart ( )

protectedpure virtual

Called whenever the driver is started.

Returns

Error code.

See also

start()

Implemented in imt::base::bsp::driver::UsartDriver, imt::base::bsp::driver::SpiDriver, imt::base::bsp::driver::PwmDriver, imt::base::bsp::driver::I2CDriver, imt::base::bsp::driver::HighLevelDriver, imt::base::bsp::driver::GpioDriver, imt::base::bsp::driver::DacDriver, imt::base::bsp::driver::CanDriver, and imt::base::bsp::driver::AdcDriver.

onStop()

template<imt::base::bsp::type::DriverType::Id TypeId>

virtual imt::base::bsp::type::ErrorCode::Id imt::base::bsp::module::DriverAbs< TypeId >::onStop ( )

protectedpure virtual

Called whenever the driver is stopped.

Returns

Error code.

See also

stop()

Implemented in imt::base::bsp::driver::UsartDriver, imt::base::bsp::driver::SpiDriver, imt::base::bsp::driver::PwmDriver, imt::base::bsp::driver::I2CDriver, imt::base::bsp::driver::HighLevelDriver, imt::base::bsp::driver::GpioDriver, imt::base::bsp::driver::DacDriver, imt::base::bsp::driver::CanDriver, and imt::base::bsp::driver::AdcDriver.

start()

template<imt::base::bsp::type::DriverType::Id TypeId>

imt::base::bsp::type::ErrorCode::Id imt::base::bsp::module::DriverAbs< TypeId >::start ( void  )

inline

Starts the driver.

This method may be called during runtime.

Returns

OK Driver is started. UNINITIALIZED Driver is not a initialized. UNSUPORTED Driver does not require start/stop and is always running. INVALID_STATE Driver is not started (already running).

stop()

template<imt::base::bsp::type::DriverType::Id TypeId>

imt::base::bsp::type::ErrorCode::Id imt::base::bsp::module::DriverAbs< TypeId >::stop ( void  )

inline

Stops the driver.

This method may be called during runtime.

Returns

OK Driver is stopped. UNINITIALIZED Driver is not a initialized. UNSUPORTED Driver does not require start/stop and is always running. INVALID_STATE Driver is not stopped (not running).

Member Data Documentation

Type

template<imt::base::bsp::type::DriverType::Id TypeId>

const imt::base::bsp::type::DriverType::Id imt::base::bsp::module::DriverAbs< TypeId >::Type = TypeId

static

Constant holding the driver type.

---

The documentation for this class was generated from the following file:

• D:/_Work/10/s/Imt.Base/Imt.Base.BSP/Driver/DriverAbs.h
